Stykra EXT Acrylic Structural Channel Bonding Tape

• Ultimate Performance Tape
• Applied in temperatures as low as 0°C* _{(when used with Stykra EXT primer or 3M Primer 94)}
• Suitable for LSE plastics and powder coated materials
• Replaces mechanical fixing methods such as rivets
• Excellent elongation properties
• Ideal for equalisation of tension across bonded joint
• Short term temperature resistance 160°C (long term 100°C)
• Low temperature resistance -40°C

Main Uses:

• Structural Sign Bonds
• Sign Channel Fixing
• Metal to Metal Fixing
• Fabrication and Panel Mounting
• PVC and Composite Bonding
• Vehicle panel, trim and badge mounting

Excellent resistance to UV, weathering and varying temperatures

We strongly advise the use of the Stykra EXT Primer or 3M Pimer 94 which greatly increases the initial bond and long term resistance to load and weather.

Why Choose Our Structural bonding Tape

Our Structural Bonding Tape is a very powerful adhesive in tape form, and has a huge number of uses in the sign industry.

Designed for very demanding applications under high stress loads, great resistance to environmental factors and external applications, i.e road signage, different materials that expand at different rates, but still need to be firmly bonded.

The ultra high sheer cohesive mass of the tape and its viscoo-elastic nature makes it extremely strong and copes with pulling, twisting, dampens vibration and absorbs shocks. Our tape is simple to use and bonds LSE plastics, metals, painted and powder coated surfaces.

• 50% of bonding strength attained after 20 minutes
• 90% of the optimum bond strength in 24 hours
• 100% of bond strength after 72 hours

Application Guide

All surfaces must be lightly abraded and cleaned with Stykra EXT Surface Cleaner, this ensures the materials are completely degreased, we then highly recommend treating both surfaces with the Stykra EXT Primer or 3M Primer 94 which creates an optimal condition for permanently bonding the two surfaces.

HOW TO STYKRA EXT BONDING TAPE

Technical Specifications
